Discover key terms and detailed descriptions to help you better understand and visualize
the essential components and terms of rotating machinery.

Glossary

API STANDARDS

API Standards for Blowers and Compressors are guidelines developed by the American Petroleum Institute (API) to ensure the safety, reliability, and efficiency of these machines in industrial applications, particularly in the oil, gas, and chemical sectors.

Key API Standards:

  1. API 617: Covers the design, testing, and operation of centrifugal compressors and axial compressors for petroleum, chemical, and gas service.
  2. API 672: Focuses on packaged centrifugal and integrally geared compressors, commonly used in process gas applications.
  3. API 673: Specifies requirements for centrifugal fans used in petroleum, chemical, and gas industries.
  4. API 681: Relates to liquid ring vacuum pumps and compressors.

Importance:

  • Ensures consistent quality and performance.
  • Improves safety by addressing critical aspects like vibration, materials, and seal design.
  • Facilitates interoperability and simplifies maintenance through standardized components and practices.
AXIAL FAN

An axial fan is a device that moves air or gas parallel to its rotational axis, commonly used in applications requiring high airflow with low pressure. The fan consists of blades mounted on a central hub, which rotates to propel air in the desired direction.



AXIAL FLOW COMPRESSOR

A compressor in which gas flows parallel to the axis of the rotating shaft. Used in applications requiring high volumes of gas at medium to high pressures.

BACKWARD CURVED BLADES

Fan or impeller blades designed to curve away from the direction of rotation, offering high efficiency at good pressure numbers and low noise.

BALANCING

The process of adjusting the distribution of mass in a rotor to minimize vibration during operation.

Static balancing ensures the mass distribution of a rotor is even so it remains stationary without tilting, correcting unbalance in one plane. Dynamic balancing, performed while the rotor is spinning, addresses unbalance in multiple planes to prevent vibrations during operation.

BEARING

A mechanical component that supports the rotating shaft and reduces friction between moving parts.

BELT DRIVE

A belt drive is a mechanical system that transmits power between rotating shafts using a flexible belt, typically made of rubber or synthetic materials. It is commonly used in industrial machinery to transfer motion efficiently, dampen vibrations, and accommodate misalignment between shafts.

CENTRIFUGAL COMPRESSOR

A compressor that increases gas pressure by accelerating it through an impeller and then decelerating it in a diffuser.

CENTRIFUGAL FAN

A fan that moves air or gas perpendicular to the axis of rotation, typically used for medium-to-high-pressure applications.

COUPLING

A device used to connect two shafts e.g.(impeller shaft and motor shaft) together at their ends to transmit power.

CRITICAL SPEED

The rotational speed at which resonance occurs in a rotating system, potentially causing vibrations or damage.

DIFFUSER

A stationary component in fans or compressors that slows down airflow and converts velocity into pressure.

DISCHARGE SIDE

The discharge side of a pump, blower, or compressor is the outlet where the fluid (liquid or gas) exits the machine after being pressurized or moved. This side typically operates at a higher pressure than the suction side and is connected to the system or process requiring the pressurized fluid.

EFFICIENCY

The ratio of useful work output to total energy input in a system, typically expressed as a percentage.

HAZOP

HAZOP (Hazard and Operability Study) is a systematic and structured technique used to identify potential hazards and operability issues in a process, system, or operation. It is commonly applied in industries such as chemical, oil & gas, and manufacturing to ensure safety and efficiency.

IMPELLER

The rotating component of a fan, pump, or compressor that imparts energy to the fluid.

INLET GUIDE VANES (IGV)

Adjustable vanes located at the inlet of a fan or compressor to control the airflow and optimize performance.

INTERCOOLER

A heat exchanger used to cool gas between compression stages in a multi-stage compressor.

MECHANICAL SEAL

A device used to prevent leakage of fluids from rotating machinery, commonly found in pumps and compressors.

MONOBLOCK BEARING

A monoblock bearing is a single-piece bearing housing that integrates both the structural support and the bearing assembly into a unified unit. This design eliminates the need for separate components, improving rigidity, alignment, and reducing the potential for misalignment or assembly errors. SERAFIMA monoblock bearings are commonly used in high-performance or compact applications where durability and precision are critical.

OVERHAUL

A comprehensive inspection, cleaning, repair, and replacement of components to restore a machine to its original specifications.

PERFORMANCE CHART

A performance chart for a blower or compressor graphically represents the relationship between flow rate, pressure, efficiency, and power consumption across operating conditions. It helps determine the optimal operating range, avoid surge or choke conditions, and ensure efficient performance.

PRESSURE RATIO

The ratio of the outlet pressure to the inlet pressure in a compressor.

ROTOR

The rotating part of a machine, including the shaft, blades, and impeller, which imparts energy to the fluid.

SCROLL

A spiral casing surrounding an impeller in pumps and fans to collect and direct fluid flow efficiently.

SHAFT

The central axis in a rotating machine that transmits mechanical power.

SHAFT SLEEVE

A shaft sleeve is a cylindrical protective cover fitted over a rotating shaft, typically in pumps, blowers or compressors, to shield it from wear, corrosion, and erosion caused by mechanical seals, Turbolabyrinth seals, packing, or fluid contact. Shaft sleeves are replaceable components that extend the life of the shaft and are commonly made from durable materials like stainless steel, bronze, or other alloys.

SIL

SIL (Safety Integrity Level) is a measure of the reliability and effectiveness of a safety instrumented function (SIF) in reducing risk in industrial processes. Defined in the international standards IEC 61508 and IEC 61511, SIL levels range from 1 to 4, with higher levels indicating greater risk reduction and reliability.

SUCTION SIDE

The side of a pump, fan, blower or compressor where fluid enters the system.

SURGE CONDITION

Surge condition in compressors or blowers occurs when the flow rate through the machine drops below a critical level, causing unstable operation characterized by flow reversal, pressure fluctuations, and vibrations. It can damage equipment and reduce efficiency, making it essential to avoid by maintaining operation above the surge limit defined in the performance chart.

THRUST BEARING

A bearing that absorbs axial forces generated in a rotating machine.

TIP SPEED

Tip speed refers to the linear velocity of the outermost edge of a rotating component, such as a fan blade, impeller, or turbine blade.

It is calculated as: Tip Speed=ω⋅r

where:

  • ω\ is the angular velocity (in radians per second).
  • r is the radius (distance from the center of rotation to the blade tip).
TURBOLABYRINTH SEAL

A TURBLABYRINTH SEAL is a type of restrictive ring seal commonly used in rotating equipment, where a carbon ring or several carbon rings (alternatively PTFE rings), often split for easier installation, is pressed against the rotating shaft or a mating surface. It provides a reliable seal by leveraging carbon's low friction and high-temperature resistance, making it ideal for applications like compressors, turbines, and pumps operating under extreme conditions.

TURNDOWN RATIO

The range of operating flow rates over which a machine can maintain efficient and stable performance.

VIBRATION ANALYSIS

A diagnostic technique used to monitor the condition of rotating equipment by analyzing its vibration patterns.

VOLUTE

A spiral casing surrounding an impeller in pumps and fans to collect and direct fluid flow efficiently.

WEAR RING

A replaceable ring fitted to reduce leakage between high-pressure and low-pressure zones in pumps and compressors.
